Service Manual 6288 RM-78/RM-268
Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
Approved 1.0
MGR
Page
(24)
17.) Lever out the IHF Speaker.
18.) Always remove the residues of the IHF Gasket. Use a
new one when reassemble.
19.) Place the dental tool in the gap between Microphone
and Cover. Ease out the Microphone as shown. Once re-
moved, it can’t be reused again.
To Next Page
