Nokia 7310 Supernova Service Manual

6
CONFIDENTIAL
Copyright © 2008 NOKIA. All rights reserved.
7310 Supernova RM-378/RM-379
Page (14)
ISSUE 1
Service Manual Level 1&2
PRODUCT CONTROLS & INTERFACES OVERVIEW7.
10
5
17
16
9
1
6
3
8
2
18
7
4
11
14
15
17
12
13
7310 Supernova RM-378/RM-379
Product Controls & Interfaces
Ver. 2.0
1
2
― Nokia AV connector (2.5mm)
3
― Earpiece
4
― Left selection key
― Right selection key
5
― Call key
― Display
6
7
― Keypad
8
― Microphone
9
― Navi™ key: hereafter referred to as scroll key
10
11
12
― Power key and end key
13
14
18
― Loudspeaker
― Volume up key
― Volume down key
17
16
― Camera lens
― Micro USB cable connector
― Charger connector
15
― Strap holder
― Battery cover release button
