Nokia 7310 Supernova Service Manual

11
CONFIDENTIAL
Copyright © 2008 NOKIA. All rights reserved.
7310 Supernova RM-378/RM-379
Page (14)
ISSUE 1
Service Manual Level 1&2
DISASSEMBLY INSTRUCTION12.
1. Nokia 7310 Supernova disassembly. 2. You will need the Standard Tool Kit v2 and the Camera
Removal Tool SS-88.
3. Press the release button and open the C-COVER with the
SRT-6.
4. Remove the C-COVER.
5. Open the clips of the A-Cover beginning on the shown side. 6. Continue on the other side.
7. Remove the A-COVER. 8. Remove the Keymat.

Nokia 7310 Supernova Specifications

General

Brand	Nokia
Model	7310 Supernova
Category	Cell Phone
Language	English
