Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
31.Okt.2006
23
Service Manual 7390 RM-140 Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved 2.0
MGR
Page
(47)
13. Use the DC-plug to remove the DC-JACK.
14. Remove the ANTENNA ASSY.
15. The PWB is secured with two snaps to the LOWER A-COVER.
16. Release the PWB...
17. and very gently, open it as shown.
18. Take a special care the on exible cords.
