Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
31.Okt.2006
29
Service Manual 7390 RM-140 Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved 2.0
MGR
Page
(47)
19. To avoid damaging the threads rst turn the screws
slightly left to engage the threads and then tighten them
lightly.
20. Tighten the screws to the correct torque in the order shown.
21. Fit the BATTERY COVER.
22. Place the KEYMAT onto the LOWER A-COVER...
23. ...and secure it into its position.
24. Using a new A-COVER ASSY t the new BUMPER.
