SAR-Hm and SAR-Hmc Chassis Installation Guide 7705 SAR-Hm and 7705 SAR-Hmc Overview
3HE 17810 AAAA TQZZA © 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
61
Figure 7 7705 SAR-Hmc Chassis
The 7705 SAR-Hm chassis is available in the following variants, each of which is
distinguished by its factory-installed carrier wireless module. The modules are
designed to support the radio protocols and bands used in the geographic regions
specified in Table 8.
Table 8 7705 SAR-Hm Chassis Variants by Carrier Wireless Module
7705 SAR-Hm Chassis
Part Number
Variant Description
3HE11600AA 7705 SAR-Hm 3G/LTE North America and EMEA
3HE11602AA 7705 SAR-Hm 3G/LTE APAC and ROW
5.5 in.
(13.97 cm)
5.0 in.
(12.7 cm)
1.5 in.
(3.81 cm)
35685
