Nokia C5-03 Service Manual

Nokia C5-03
RM-697, RM-
719
Service Manual Level 1&2
10
Co nf id e nt ial | Co p y rig ht © 2011 Nokia | A ll rights reserved
V e rs io n 3 .0
7. SERVICE DEVICES
BL-4U Battery
CA-101D
AC-8 Travel Charger
SS-88 Camera Removal tool
Nokia Standard Toolkit (v2)
For more information, refer to the
Service Bulletin (SB-011) on Nokia
Online. Supplier or manufacturer
contacts for tool re-order can be
found in “Recommended service
equipment” document on Nokia
Online.

Nokia C5-03 Specifications

General

Display	TFT resistive touchscreen, 16M colors
Resolution	360 x 640 pixels, 3.2 inches (~229 ppi pixel density)
Operating System	Symbian OS v9.4, Series 60 rel. 5
Processor	600 MHz ARM 11
RAM	128 MB
Main Camera	5 MP
Video	480p@15fps
Battery	Removable Li-Ion 1000 mAh battery (BL-4U)
Talk time	Up to 11 h 30 min (2G) / Up to 4 h 30 min (3G)
Music play	Up to 35 h
Dimensions	105.8 x 51 x 13.8 mm, 65 cc (4.17 x 2.01 x 0.54 in)
Weight	93 g (3.28 oz)
Network	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
GPRS	Class 32
EDGE	Class 32
Announced	2010, October
Status	Discontinued
SIM	Mini-SIM
GPU	No
Card slot	microSD, up to 16 GB (dedicated slot), 2 GB included
Alert types	Vibration; MP3, WAV ringtones
Loudspeaker	Yes
3.5mm jack	Yes
WLAN	Wi-Fi 802.11 b/g
Bluetooth	2.0, A2DP
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Sensors	Accelerometer, proximity
Browser	WAP 2.0/xHTML, HTML, Adobe Flash Lite
Java	Yes, MIDP 2.1
Internal Storage	40 MB
Stand-by	Up to 576 h (3G)
3G bands	HSDPA 900 / 2100
GPS	Yes, with A-GPS
Colors	Black, Pink
