Nokia C5-03

Nokia C5-03
RM-697, RM-
719
Service Manual Level 1&2
12
Co nf id e nt ial | Co p y rig ht © 2011 Nokia | A ll rights reserved
V e rs io n 3 .0
9. DISASSEMBLY INSTRUCTIONS
1. Nokia C5-03 disassembly.
2. For disassembling you need the Nokia Standard
Toolkit version 2, the camera removal tool SS-88, an
AV plug and a DC plug.
3. Protect the TOUCH PANEL with protective film. 4. Lift up the BATTERY COVER from the release
notches to detach it.
5. Remove the BATTERY COVER.
6. If there is a battery inserted, remove it also.
