Nokia C5-03 User Manual

DNS addresses — Enter the IP addresses of the primary and secondary DNS servers, if
required by your service provider. To obtain these addresses, contact your internet
service provider.
Proxy server address — Enter the address of the proxy server.
Proxy port number — Enter the port number of the proxy server.
WLAN access point settings
Select Menu > Settings and Connectivity > Destinations > Access point, and follow
the instructions.
Edit a wireless LAN (WLAN) access point
Select an access point group and access point marked with
. Follow the instructions
from your WLAN service provider.
Select from the following:
WLAN network name — Select Enter manually or Search for networks. If you select
an existing network, the WLAN network mode and WLAN security mode are determined
by the settings of its access point device.
Network status — Define whether the network name is displayed.
WLAN network mode — Select Ad-hoc to create an ad hoc network and to allow
devices to send and receive data directly; a WLAN access point device is not needed. In
an ad hoc network, all devices must use the same WLAN network name.
WLAN security mode — Select the encryption used: WEP, 802.1x, orWPA/WPA2
(802.1x and WPA/WPA2 are not available for ad hoc networks). If you select Open
network, no encryption is used. The WEP, 802.1x and WPA functions can be used only
if the network supports them.
Homepage — Enter the web address of the starting page.
Use access point — Set the device to create a connection using this access point
automatically or after confirmation.
The available options may vary.
View your active data connections
Select Menu > Settings and Connectivity > Connection mgr..
In the active data connections view, you can see your data connections:
data calls
packet data connections
WLAN connections
Connectivity 101

Nokia C5-03 Specifications

General

Display	TFT resistive touchscreen, 16M colors
Resolution	360 x 640 pixels, 3.2 inches (~229 ppi pixel density)
Operating System	Symbian OS v9.4, Series 60 rel. 5
Processor	600 MHz ARM 11
RAM	128 MB
Main Camera	5 MP
Video	480p@15fps
Battery	Removable Li-Ion 1000 mAh battery (BL-4U)
Talk time	Up to 11 h 30 min (2G) / Up to 4 h 30 min (3G)
Music play	Up to 35 h
Dimensions	105.8 x 51 x 13.8 mm, 65 cc (4.17 x 2.01 x 0.54 in)
Weight	93 g (3.28 oz)
Network	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
GPRS	Class 32
EDGE	Class 32
Announced	2010, October
Status	Discontinued
SIM	Mini-SIM
GPU	No
Card slot	microSD, up to 16 GB (dedicated slot), 2 GB included
Alert types	Vibration; MP3, WAV ringtones
Loudspeaker	Yes
3.5mm jack	Yes
WLAN	Wi-Fi 802.11 b/g
Bluetooth	2.0, A2DP
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Sensors	Accelerometer, proximity
Browser	WAP 2.0/xHTML, HTML, Adobe Flash Lite
Java	Yes, MIDP 2.1
Internal Storage	40 MB
Stand-by	Up to 576 h (3G)
3G bands	HSDPA 900 / 2100
GPS	Yes, with A-GPS
Colors	Black, Pink
