Nokia C5-03 User Manual

Network mode — Select which network to use. If you select Dual mode, the device
uses the GSM or UMTS network automatically, according to the network parameters and
the roaming agreements between the wireless service providers. For details and
roaming costs, contact your network service provider. This option is shown only if
supported by the wireless service provider.
A roaming agreement is an agreement between two or more service providers to enable
the users of one service provider to use the services of other service providers.
Operator selection — Select Automatic to set the device to search for and select one
of the available networks, or Manual to manually select the network from a list. If the
connection to the manually selected network is lost, the device sounds an error tone
and asks you to reselect a network. The selected network must have a roaming
agreement with your home network.
Cell info display — Set the device to indicate when it is used in a cellular network
based on microcellular network (MCN) technology and to activate cell info reception.
Wireless LAN
Your device can detect and connect to wireless local area networks (WLAN). Using a
WLAN, you can connect your device to the internet and compatible devices that have
WLAN support.
About WLAN
To use a wireless LAN (WLAN) connection, it must be available in the location, and your
device must be connected to the WLAN. Some WLANs are protected, and you need an
access key from the service provider to connect to them.
Note: Using WLAN may be restricted in some countries. For example, in France,
you are only allowed to use WLAN indoors. For more information, contact your local
authorities.
Features that use WLAN, or that are allowed to run in the background while using other
features, increase the demand on battery power and reduce the battery life.
Your device supports the following WLAN features:
• IEEE 802.11b/g and WAPI standards
• Operation at 2.4 GHz
• Wired equivalent privacy (WEP) with keys up to 128 bits, Wi-Fi protected access
(WPA), and 802.1x authentication methods. These functions can be used only if they
are supported by the network.
96 Connectivity

Nokia C5-03 Specifications

General

Display	TFT resistive touchscreen, 16M colors
Resolution	360 x 640 pixels, 3.2 inches (~229 ppi pixel density)
Operating System	Symbian OS v9.4, Series 60 rel. 5
Processor	600 MHz ARM 11
RAM	128 MB
Main Camera	5 MP
Video	480p@15fps
Battery	Removable Li-Ion 1000 mAh battery (BL-4U)
Talk time	Up to 11 h 30 min (2G) / Up to 4 h 30 min (3G)
Music play	Up to 35 h
Dimensions	105.8 x 51 x 13.8 mm, 65 cc (4.17 x 2.01 x 0.54 in)
Weight	93 g (3.28 oz)
Network	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
GPRS	Class 32
EDGE	Class 32
Announced	2010, October
Status	Discontinued
SIM	Mini-SIM
GPU	No
Card slot	microSD, up to 16 GB (dedicated slot), 2 GB included
Alert types	Vibration; MP3, WAV ringtones
Loudspeaker	Yes
3.5mm jack	Yes
WLAN	Wi-Fi 802.11 b/g
Bluetooth	2.0, A2DP
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Sensors	Accelerometer, proximity
Browser	WAP 2.0/xHTML, HTML, Adobe Flash Lite
Java	Yes, MIDP 2.1
Internal Storage	40 MB
Stand-by	Up to 576 h (3G)
3G bands	HSDPA 900 / 2100
GPS	Yes, with A-GPS
Colors	Black, Pink
