Nokia C6-01
RM-718 / RM-601
18 Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0
37) Remove the IHF SPEAKER. Do not use it again.
Discard it.
38) Use the dental tool to remove the IHF SPEAKER
ADHESIVE. Do not use it again. Discard it. Be careful
not to injure yourself with the sharp end of the
dental tool!
39) Use the dental tool to lever up the FLASH PWB.
40) Remove the FLASH PWB with the tweezers.
41) Use the dental tool to lever up the DC JACK. 42) Remove the DC JACK with the tweezers.
