Nokia N86 8MP
RM-484 / RM-485 / RM-486
Service Manual Level 1&2
20 Confidential
Copyright © 2009 NOKIA
All rights reserved
Version 1.0
ISSUE 1
12. SOLDER COMPONENTS
Solder components only for Level 2
V2422
S2542S2541 X7551
X7550S2543
X3300
F3300V2427
Ver. 1.0
V2420
X1000 V2428
V2429
V2421
