Service Manual N91 RM-43 / RM-158
Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved 3.0
MGR
Page
(34)
49. Note not to destroy the fixing joint. 50. Lever out the HDD ASSEMBLY.
51. Lift out the HDD ASSEMBLY. Never remove it by pulling at the
flex foil.
