Band Channel (RX and
TX)
Input frequency
(MHz)
Offset (kHz) Power level
(dBm)
GSM900 37 942.46771 67.710 -90
GSM1800 700 1842.86771 67.710 -90
GSM1900 661 1960.06771 67.710 -90
Figure 43 RF Controls window
Receiver (RX) troubleshooting
Receiver troubleshooting
Apply a signal according to the table in General instructions for RX troubleshooting (page )
RM-237
Nokia Customer Care RF Troubleshooting and Manual Tuning Guide
Page 7 –8 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.
