RJ-169 Rework jig
RJ-169 is a rework jig used when servicing the WCDMA PA (N7540)
component. It is used together with the ST-59 stencil.
RJ-73 Rework jig
RJ-73 is a rework jig used when servicing the N7601 component. It is
used together with the ST-29 rework stencil.
RJ-93 Rework jig
RJ-93 is used as a rework jig for the Front End Module (FEM).
This rework jig takes the FEM or power amplifier (PA) module (N7520)
for spreading the soldering paste to the component. Must be used
together with the ST-40 stencil.
SB-6 Bluetooth test and
interface box (sales
package)
The SB-6 test box is a generic service device used to perform Bluetooth
bit error rate (BER) testing, and establishing cordless FBUS connection
via Bluetooth. An ACP-8x charger is needed for BER testing and an
AXS-4 cable in case of cordless interface usage testing .
Sales package includes:
• SB-6 test box
• Installation and warranty information
SPS-1 Soldering Paste
Spreader
RM-243
Service Tools and Service Concepts
Page 2 –10 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.
