Nokia RM-243 - Page 33

SPS-2 Soldering paste
spreader
SRT-6 Opening tool
SRT-6 is used to open phone covers.
SS-102 Front camera
removal tool
The front camera removal tool SS-102 is used to remove/attach a front
camera module from/to the camera socket of the phone PWB.
SS-46 Interface adapter
SS-46 acts as an interface adapter between the flash adapter and
FPS-10.
SS-62 Generic flash adapter
base for BB5
• generic base for flash adapters and couplers
• SS-62 equipped with a clip interlock system
• provides standardised interface towards Control Unit
• provides RF connection using galvanic connector or coupler
• multiplexing between USB and FBUS media, controlled by VUSB
RM-243
Service Tools and Service Concepts
Issue 1 COMPANY CONFIDENTIAL Page 2 –11
Copyright © 2007 Nokia. All rights reserved.
