Service Manual Level 1 and 2
Nokia 220
RM-969, RM-970, RM-971
Version 1.0
Solder components
V2052 V2051
V6000
V3001
H6400
F7051 X8001
V2002
X2080R7050
V6502
USB
ASIP
USB
fuse
Camera
connector
Bipolar
transistor
Bipolar
transistor
Bipolar
transistor
Battery
connector
Flashlight
LED
Display
connector
Keypad
LED
Battery
ASIP
TOP
BOTTOM
©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
