Arrow icons on the left and right ends of navi pane
indicate the possibility to move in the corresponding
directions. (With tabs, the arrows are only displayed
when all tabs are not visible.)
Figure 5-54. Arrows in navi pane.
Editing indicators When an editor is in use in the main pane, the
indicators related to editing parameters are
displayed in the navi pane. They indicate things such
as the editing mode (numeric/alphanumeric),
character case, predictive text status, and available
space.
Figure 5-55. Editing indicators in navi pane.
Audio volume indicator Used in applications where audio volume
adjustment is necessary, as in Phone.
Figure 5-56. Volume indicator in navi pane.
Editing indicators in pop-up windows
When a pop-up window contains an editor that needs editing indicators, it is not
feasible to use the navi pane for the indicators. For this purpose, a specific area in
the pop-up window, above the editing field, can be used for displaying the editing
indicators. (See the Text editing section for an example.)
Soft indicators
Soft indicators are textual indicators displayed in the main pane of the idle state.
Examples of cases where a soft indicator can be used are call charges indication and
MCN (Micro-Cellular Network) area indication.
Figure 5-57. Soft indicators in the main pane.
66
