This user guide applies to the following models: TA-1097, TA-1095, TA-1100,
TA-1085 and TA-1096.
Fingerprint sensor1.
Flash2.
Main camera3.
Headset connector4.
Microphone5.
SIM and memory cards6.
Front camera7.
Earpiece8.
Proximity sensor9.
Volume keys10.
Power/Lock key11.
USB connector12.
Microphone13.
Loudspeaker14.
PARTS AND CONNECTORS, MAGNETISM
Do not connect to products that create an output signal, as this may damage the
device. Do not connect any voltage source to the audio connector. If you connect an
external device or headset, other than those approved for use with this device, to
the audio connector, pay special attention to volume levels.
Parts of the device are magnetic. Metallic materials may be attracted to the device.
Do not place credit cards or other magnetic stripe cards near the device for
extended periods of time, since the cards may be damaged.
Insert or remove the SIM and memory card
INSERT SIM AND MEMORY CARD
Open the SIM and memory card tray: push the tray opener pin in the tray hole 1.
Nokia 7.1 User Guide
© 2018 HMD Global Oy. All rights reserved.
7
