Nokia X1-00 Service Manual

Nokia X1-00
RM-732 / RM-733
Service Manual Level 1&2
12
Co nf id e nt ial | Cop yrig ht © 2011 Nokia | A ll right s reserved
V e rs ion 1 .0
9. DISASSEMBLY INSTRUCTIONS
1) Nokia X1-00 disassembly.
2) You must use the Nokia Standard Toolkit version
2. You will also need the DC plug and the AV plug.
3) Protect the A-C OVER with the protective f ilm. 4) Open the BATTERY COVER by using the release
notch.
5) Remove the BATTERY COVER.
6) Unscrew the two Torx+ size 4 screws. Do not use
them again. Discard them.
