Nokia X1-00 - Page 16

Nokia X1-00
RM-732 / RM-733
Service Manual Level 1&2
16
Co nf id e nt ial | Cop yrig ht © 2011 Nokia | A ll right s reserved
V e rs ion 1 .0
25) Peel of the DOMESHEET.
26) Remove the DOMESHEET. Do not use it again.
Discard it.
27) Use the AV plug to lift the AV J ACK from its socket.
28) Remove it with the tweezers.
29) Use the DC plug to lif t the DC J ACK from its socket. 30) Remove it with the tweezers.
