Nokia X3
RM-540
Service Manual Level 1&2
13 Confidential | Copyright © 2009 Nokia | All rights reserved Version 1.0
7) Remove the NUMERIC KEYMAT ASSY and the E-
COVER ASSY as shown.
8) Then separate the NUMERIC KEYMAT ASSY from
the E-COVER ASSY. The NUMERIC KEYMAT ASSY must
always be renewed.
9) Unscrew the four TORX+ size 6 screws in the
order shown. Do not use them again. Discard them.
10) Before removing the D-COVER ASSY, open the
USB DOOR.
11) Release the D-COVER ASSY as shown. 12) Use the SS-93 to carefully lift up the board to
board connector SHIELD LID. The board to board
connector SHIELD LID has to be always renewed.
