model no. 052-9339-8
Instruction Manual
IMPORTANT: Please read and under
Total weight of fan plus light kit are 8.6.kgs
stand this manual before any assembly. Before
beginning assembly of product, make sure all parts are present. Compare parts
with exploded view. If any part is missing, or if you have any questions, contact
customer service at 1-866-827-4985 (toll free).
Miles 52" Ceiling Fan
Toll Free: 1-866-827-4985

Questions and Answers

  • L
    Laura WardAug 5, 2025
    What to do if my NOMA 052-9339-8 does not start?
    • C
      cgutierrezAug 5, 2025
      If your NOMA Fan isn't starting, first check your main fuse and branch circuit fuses, or the circuit breaker, and repair if necessary. Also, inspect all wire connections to the fan and housing wiring, repairing as needed. Ensure the main power is off before checking the wires.
  • M
    Mr. Scott PetersonAug 12, 2025
    What to do if the light on my NOMA 052-9339-8 does not work?
    • J
      Jessica DonaldsonAug 12, 2025
      If the light on your NOMA Fan isn't working, first ensure the wire connector in the switch housing is connected. If that's not the issue, try unscrewing the light bulb and discarding it properly, as it may be faulty. Also, this fan is equipped with a 70 W LIMITER that will automatically turn the light off if the total wattage exceeds the maximum wattage level, so turn the power OFF and replace the bulb with lower wattage bulbs so that the total wattage is below 70 W.
  • E
    ericgriffithAug 17, 2025
    How to fix a noisy NOMA 052-9339-8 Fan?
    • J
      Juan GrahamAug 17, 2025
      If your NOMA Fan is noisy, several issues could be the cause. Start by tightening any loose blade screws with a screwdriver. Then, check and tighten the screws on the mounting bracket or canopy, as well as the screws securing the decorative housing to the hanger. Also, check the screws securing the downrod to the hanger. If noise persists, hand-tighten any loose glass shades or bulbs. If wire connectors are vibrating against the inside of the canopy, disconnect the power at the fuse box, loosen the canopy, and reposition the connectors. Ensure the light kit or light bulb is firmly attached by removing and re-attaching it. Make sure the canopy is not touching the ceiling. Finally, check and tighten the motor housing screws if they have come loose.
  • H
    Heather BrownAug 23, 2025
    Why is my NOMA Fan wobbling?
    • U
      ufordAug 23, 2025
      If your NOMA Fan wobbles or shakes too much, make sure the screws securing the fan blade clips to the motor are fastened and tightened. Also, tighten the screws of the fan blade to the blade clip securely. Ensure the canopy and mounting bracket are tightened securely to the ceiling joist. Finally, check if the blades are unbalanced by measuring the distance from a point on the ceiling to the tip of each blade. Adjust accordingly if the blade levels are not equal, consulting the Balancing Kit Manual.
  • L
    Leonard WhiteAug 29, 2025
    Why doesn't my NOMA 052-9339-8 Fan move much air?
    • K
      Kevin PotterAug 29, 2025
      If your NOMA Fan isn't moving much air, it might be in reverse, with the blades moving clockwise. Counter-clockwise (forward) is recommended in warm weather. Also, make sure the fan is in the center of the room with at least 12" (30 cm) between the blade ends and any walls or obstructions.

Summary

Exploded View

Important Safety Instructions

Rules for Safe Installation

Tools Required for Assembly

Assembly

Preparing for Installation

Steps prior to assembly, including unpacking and power disconnection.

Choosing a Location

Guidelines for selecting an optimal installation site for the fan.

Mounting Options

Details on various methods for mounting the ceiling fan.

Mounting Bracket Installation

Instructions for securely attaching the fan's mounting bracket.

Blade Attachment to Motor

Procedure for connecting the fan blades to the motor assembly.

Downrod and Wiring Setup

Guidance on installing the downrod and initial wire connections.

Electrical Wiring Connections

Instructions for connecting fan wiring to the main power supply.

Remote and Receiver Pairing

Steps to link the remote control with the fan's receiver unit.

Receiver Assembly Installation

Procedure for installing the receiver within the fan's housing.

Fan Assembly to Bracket

Securing the main fan unit to the ceiling-mounted bracket.

Operation

Light Kit Installation

Steps for installing the light kit and bulbs.

Fan Speed and Power Control

How to use the remote to adjust fan speed and turn it on/off.

Fan Direction Control

Explanation of the reverse switch for airflow direction.

Maintenance

Care and Cleaning

Troubleshooting

Noisy Fan Diagnosis

Possible causes and solutions for a noisy ceiling fan.

Fan Power Failure

Troubleshooting steps when the fan fails to power on.

Light Fixture Issues

Solutions for when the fan's light does not illuminate.

Low Airflow Problems

Reasons and fixes for reduced fan air circulation.

Fan Wobbling or Shaking

How to correct excessive fan movement.

Environmental Protection

Warranty Information

NOMA 052-9339-8 Specifications

General IconGeneral
BrandNOMA
Model052-9339-8
CategoryFan
LanguageEnglish
