185
2� For safe installation bend the flaps inside into the dashboard�
3� If necessary, use a metal strip to secure the rear side of the unit�
The strip can be bent to the necessary angle by hand�
Dashboard
Fireproof partition
Release the dashboard
Attach the rear bracket screws and the
rear cable bundle and safely secure
the device in place�
4� To release the unit insert the keys on both sides and pull the unit
out of the dashboard�
Note:
- Store small items in a location that is not accessible to
children�
- Use only the supplied bolts for the installation�
- The installation method is modified depending on the car
model and the supplied parts� You should have the unit
installed by a qualified technician�
Detaching the front panel
Press button to release the control panel from the main unit� The
panel will be disconnected and can be removed� Likewise, after
disconnecting the panel, you may insert an SD card into the slot to
playback multimedia files�
