187
Connecting leads
Use the adaptor bundle connected to the device’s multiconnector
and the relevant inputs and outputs on the other side� Ensure
that the connections are properly made and the insulation of both
connected and disconnected lead is good!
Connector/Object Connect to
1 Pink lead Parking brake (-)
2 Violet lead Rear-view camera (B+)
3 ISO connector See previous description
4 Yellow cable Video output
5 Red cable Rear line output (R - right)
6 White cable Rear line output (L - left)
7 Red cable Front line output (R - right)
8 White cable Front line output (L - left)
9 Red cable Audio input (R - right)
10 White cable Audio input (L - left)
11 Yellow cable Video input
12 Brown cable Video camera
13 Blue cable Subwoofer
14 White lead OE SWC AD Line 1
15 Green lead OE SWC AD Line 2
16 Black lead OE SWC AD Line Ground (earth)
17 Black cable Radio antenna
18 DAB connector See previous description
