Installation Manual 13
- Make sure that the bend of the condenser bafe is
ush with the bottom edge of the door frame of the
upper side-wall exhaust vent.
- Make sure that the top edge of the condenser bafe is
1/4 inch or less [15] from the lower rear corner of the
condenser.
If the enclosure depth is 26 inches or more (See Art01787):
- Install a wood, aluminum or galvanized steel top bafe [13]
between the top of the refrigerator and the top of the upper
exhaust vent [24].
- Make sure that the top bafe is less than 1/4 inch [15]
from the top of the refrigerator and bafe overlaps the
refrigerator 1 inch or less.
- Make sure that the bafe is against the wall of the
vehicle at the top of the upper exhaust vent and less
than 1/4 inch above the opening for the upper exhaust
vent.
- Install solid box bafe [21] between the lower intake vent
and the upper exhaust vent.
- Make the solid box bafe either from wood or from an
aluminum or galvanized-steel sheet.
- Make sure that the bottom of the solid box bafe is
18 inches to 18 1/2 inches above the bottom of the
enclosure [17] (4 1/4 inches to 4 3/4 inches above the
top of the lower intake vent opening REF) [18].
- Make sure that the back of the solid box bafe is
perpendicular to the bottom of the enclosure.
- Make sure that the horizontal top of the solid box bafe
is even with the bottom edge of the upper exhaust vent
[24].
- Make sure that the vertical top edge of the solid box baffle is 1/2 inch or less [170] below and 1/4 inch or less behind [15] the
lower rear corner of the condenser [11].
Art01787
15
13
15
15
24
21
25
18
17
9
27
170
11
