Installation Manual 7
You can change enclosures that were made for Norcold model N8XX refrigerators so that you can put Norcold model 121X refrigerators
into them.
To change the Norcold model N8XX refrigerator enclosure [130] into the Norcold model 121X refrigerator enclosure [131] (See
Art01597):
- Increase the height of the enclosure by 3 3/8 inches [132].
- Increase the width of the enclosure by 8 13/16 inches [133].
- Make sure to add the additional width to the left side of the enclosure (as looking at the rear of the refrigerator).
Install the necessary bafes only as written in the “Install the Upper and Lower Vents” section of this manual.
The locations of the 12 VDC supply, the 120 VAC supply, and the propane gas supply line do not change.
Optional Installation
12
Art01597
12
11
9
130
131
132
N8XX
120X
133
