Burner
Applies heat to the cooling unit
when it has the correct amount of
LP gas and air.
Ignition Electrode
Sparks the Burner to ignite the
flame when supplied with energy
from the Ignition Module.
Sense Electrode
Senses the heat of the flame and
tells the Ignition Module if a flame
is present or not.
Figure 5.17 Burner
Figure 5.18 Ignition Electrode
Figure 5.19 Sense Electrode
