General Information and Specification
OPERATING LIMITS - ALL
MODELS
AC Mode: 132 VAC Max., 108
VAC Min.
15. 4 VDC Max., 10.5
VDC Min.
DC Mode: 15.4 VDC Max., 11.5
VDC Min.
Gas Mode: 11" W.C.
15.4 VDC Max., 10.5
VDC Min.
MODELS 8652, 8653
RATINGS
1200 Btu/Hr Input
LP Gas Mode:
11" W.C.
LP14 Orifice
12 Volts DC control voltage
AC Mode:
110 Volts AC, 170 Watts
12 Volts DC control voltage
DC Mode (3-Way only):
12 Volts DC
MODELS 8662, 8663
RATINGS
1450 Btu/Hr Input
LP Gas Mode:
11" W.C.
LP16 Orifice
12 Volts DC control voltage
AC Mode:
110 Volts AC, 300 Watts
12 Volts DC control voltage
DC Mode (3-Way only):
12 Volts DC
MODELS 8682,8683
RATINGS
1500 Btu/Hr Input
LP Gas Mode:
11" W.C.
LP16 Orifice
12 Volts DC control voltage
AC Mode:
110 Volts AC, 300 Watts
12 Volts DC control voltage
DC Mode (3-Way only):
12 Volts DC
CURRENT DRAWS - 8652, 8653
Automatic ignition - Less than 250 milliamps or .25 amps
AC Heating Element - 1.5 amps at 110 Volts AC
1.7 amps at 120 Volts AC
DC Heating Element - 9.2 amps at 12 Volts DC
10.7 amps at 14 Volts DC
CURRENT DRAWS - 8662, 8663, 8682, 8683
Automatic ignition - Less than 250 milliamps or .25 amps
Humidity Heater - 240 milliamps or .24 amps
Interior Lamp (when door open) - 900 milliamps or .90 amps
AC Heating Element - 2.7 amps at 110 Volts AC
2.9 amps at 120 Volts AC
DC Heating Element - 13.8 amps at 12 Volts DC
16.1 amps at 14 Volts DC
OPERATION WHERE THESE SPECIFICATIONS ARE EXCEEDED MAY
CAUSE DAMAGE AND WILL VOID REFRIGERATOR WARRANTY.
5-2
