AC Heating Element
Applies specific amount of heat
to the cooling unit, providing 120
volts AC is present to the refrig-
erator.
DC Heating Element
Applies specific amount of heat
to the cooling unit, providing the
DC input voltage is correct. The
DC Heating Element does not
have the capability to cool the re-
frigerator from an initial start, but
has the capability to maintain the
temperature for a short duration.
Figure 5.20 Illustration of Heater Types
Figure 5.21 DC Heater (current)
5-13
