Thermistor
Senses the temperature of the re-
frigerator interior and changes the
resistance to the temperature sens-
ing circuit telling the refrigerator
when to turn off and on.
Figure 5.22a Type A Thermistor
Figure 5.22c Type C Thermistor And It’s Fin Location
Figure 5.22b Type B Thermistor
5-14
