Owner’s Manual 6
3. Unplug wire harness connector
4. Install the replacement light
5. Install the cover.
Crisper(s):
The crisper(s) are located at the bottom of the fresh food compartment and supply a storage area to
preserve fruit and vegetable freshness. Make sure that you always push the crispers fully in.
Do not wash the crispers in a dishwasher. The crispers are not dishwasher safe.
Door bins:
You may put the door bins of the fresh food compartment in a location that best meets your needs. To remove the bins, lift them over
the locator and pull them away from the door. The center door bins in each door are equipped with a screw to ensure compliance with
Child Entrapment regulations. To remove the center door bin, remove the plastic cap and then remove the screw.To install the bins,
push them onto the locator. (ART02783)
Do not wash the door bins and bin slides in a dishwasher. The door bins and bin slides are not dishwasher safe.
Adjustable shelves:
The shelves in the freezer and the fresh food compartment are made so you can remove
them or move them. To remove or move each shelf of the fresh food compartment:(ART
02780)
- Remove the cap and screw from the retainer of each shelf at the side of the
refrigerator.
- Pull each shelf forward out of the slot.
- Push each shelf fully into the slot that you wish.
- Attach the retainer with the screw and replace cap.
Shelf Divider
To remove or move the shelf divider:
- Remove the screw [1] from the divider [2] and fastening bracket [3]
[ART 02792]]
- Remove the cap and screw from the retainer of the shelf at the side of the refrigerator [ART 02780]
- Pull the shelf [4] forward
- With the shelf forward, pull the divider [2] forward and down slightly to detach from shelf then pull backwards to remove
- Slide shelf back into place and reinstall screw and cap
NOTICE
NOTICE
ART 02780
ART 02783
ART 02792
1
2
3
4
