Norcold ELITE N20DCX - Refrigerator Operation Controls; Power ON;OFF Control; Temperature Setting

Owner’s Manual 7
Bin Divider – Freezer
To remove or move the bin divider:
- Remove the screw (1) from the divider [ART 02793]
- Lift the divider [2] out of the bin.
Controls:
-Touch and release the ON/OFF [1] button to turn the refrigerator on.
(ART 02773)
- If the indicator light, above the button, glows solid blue, it means the
refrigerator is operating correctly.
The freezer compartment and cabinet compartment work
independent of each other and both must be adjusted to
their desired temperature setting.
- Touch the FREEZER COMPARTMENT [5] button to set the compartment temperature setting.The Blue LED will turn ON.(ART 02774 )
-Using the + [4] or – [2] buttons adjust the temperature setting.
- The mode [3] will display the temperature setting
- 1 is the warmest setting
- 5 is the coldest setting
Operation
NOTICE
1
6
ART 02773
7
4
3
2
5
ART 02793
1
2
1
6
ART 02774
7
4
3
2
5
