Owner’s Manual 15
3. Put the screws though the mounting anges and into the wall.
4. Attach the door to the refrigerator
The rear of the refrigerator has sharp edges and corners. To prevent cuts or abrasions when working on the
refrigerator, be careful and wear cut resistant gloves.
5. Open the lower intake vent and put the screws through refrigerator and into the oor.
To avoid possible propane gas leaks, always use two wrenches to loosen and tighten the gas supply line at
the refrigerator’s manual shut off valve.
6. Attach the gas supply line to the manual shut off valve of the refrigerator.
7. Open the valve at the propane gas tank(s).
Do not allow the leak checking solution to touch the electrical components. Many liquids are electrically
conductive and can cause a shock hazard,electrical shorts, and in some cases re.
8. Examine the gas supply line for leaks.
9. Connect the DC wiring to the refrigerator:
- Install the DC fuse or connect the DC wiring to the battery or the converter.
- Connect the DC wires from the refrigerator.
10. Connect the AC power cord to the receptacle.
Replacement Parts
You may purchase replacement parts through your local RV dealer or an authorized Norcold Service Center.
Wiring Diagram and Pictorial
The parts of the wiring diagram are (See Art01775):
The parts of the wiring pictorial are (See Art01776):
AC heater .................................................................................................................................................................................................A
Thermister ............................................................................................................................................................................................... B
Gas valve................................................................................................................................................................................................. C
Igniter....................................................................................................................................................................................................... D
Temperature switch (optional) ................................................................................................................................................................. E
Fan (optional) ...........................................................................................................................................................................................F
DC heater (optinal) ..................................................................................................................................................................................G
Chassis ground........................................................................................................................................................................................ H
DC board (optional) ..................................................................................................................................................................................I
Switched 12 VDC .....................................................................................................................................................................................1
Fused continuous 12 VDC........................................................................................................................................................................2
Communications ....................................................................................................................................................................................... 3
Display ground..........................................................................................................................................................................................4
Auxiliary ground (optional) ........................................................................................................................................................................ 5
Auxiliary +12 VDC (optional) ....................................................................................................................................................................6
Gas valve +12 VDC .................................................................................................................................................................................. 7
5 A Fuse DC ...........................................................................................................................................................................................F1
8A Fuse AC.............................................................................................................................................................................................F2
30 A Fuse DC .........................................................................................................................................................................................F3
WARNING
!
WARNING
!
CAUTION
!
