Installation Manual 4
Install the Lower and Upper Vents
1. Using the following chart, decide which vents and rough
opening (RO) sizes to use:
Certied Vent P/N RO Height RO Width
Upper Roof 622293 N/A N/A
Exhaust Cap
Upper Roof 616319 24 in. 5 1/4 in.
Exhaust Vent
Upper Exhaust 621156 13 3/4 in. 21 1/2 in.
& Lower Intake
Plastic
Lower Square 616010 9 3/4 in. 19 3/8 in.
Corner Intake
2. Install the lower intake vent (See Art01598, Art01599, and
Art01602):
NOTE: The lower intake vent is also the service access opening
for the components on the rear of the refrigerator.
WARNING: Make sure the bottom of the opening of the
lower intake vent is even with or immediately below the
oor level. This allows any leaking propane gas to escape
to the outside and not to collect at oor level.
- Make sure the bottom of the opening of the lower intake vent
[9] is even with or immediately below the oor level.
- Align the lower intake vent vertically below the coils [10] and
the condenser [11] of the refrigerator.
3. Install the upper exhaust vent:
CAUTION: Make sure that no sawdust, insulation, or
other construction debris is on the refrigerator or in the
enclosure. Debris can cause a combustion hazard and
prevent the refrigerator from operating correctly.
NOTE: Tighten the screws of the upper roof exhaust cap to
10 inch-pounds max. Also make sure that the air ow
around the upper roof exhaust cap is not blocked or
decreased by other roof mounted features such as a
luggage carrier, an air conditioner, a solar panel, etc.
- If the design of the vehicle allows, install the roof exhaust
vent [12] directly above the condenser [11] of the refrigerator
(See Art01598):
- Install a bafe [13] to prevent stagnant hot air in the area
[14] above the refrigerator.
Key Refrigerator Dimensions
1. Make sure the enclosure is 59.88 - 60.01 inches high for
N82X, N82XXX, N84X, N84XXX, N84XIM, and N84XIMXX
models or 52.88 - 53.01 inches high for N62X, N62XXX, N64X,
N64XXX, N64XIM, and N64XIMXX models x 23.50 - 23.63
inches wide x 24.00 inches deep.
2. Make sure the oor is solid and level.
- The oor must be metal or a wood panel and extend the full
width and depth of the enclosure.
- The oor must be able to support the weight of the
refrigerator and its contents.
3. Make sure there are no adjacent heat sources such as a
furnace vent, a hot water heater vent, etc.
4. If there is more than 1/2 inch between either side of the
refrigerator and the inside of the enclosure:
- Fill the space with berglass insulation or add a bafe to
eliminate the excess clearance.
- Make sure that the rear of the batt-type insulation is
between 18 - 19 inches from the face of the enclosure.
- Securely attach the batt-type insulation to the enclosure
so that it remains in this position during refrigerator
installation, if it becomes wet, and in windy conditions.
Assemble the Enclosure for the Refrigerator
These key refrigerator dimensions are for your reference as
necessary (See Art01733).
Refrigerator cabinet width w/o trim - 23.47 in. max. .....................1
Refrigerator width overall w/ trim - 24.6 in. ...................................2
Refrigerator cabinet to side trim - 0.80 in. ....................................3
Refrigerator cabinet height w/o trim..............................................4
N600 models - 52.85 in. max.
N800 models - 59.85 in. max.
Refrigerator height overall w/ trim.................................................5
N600 models - 54.5 in.
N800 models - 61.5 in.
Refrigerator cabinet to top/bottom trim - 0.93 in. ..........................6
Enclosure wall to hinges - 1.10 in. ................................................7
Refrigerator cabinet to center of handles .....................................8
N600 models - 32.5 in.
N800 models - 39.5 in.
!
!
