Installation Manual 9
- Reverse each door handle and put the lower door handle on
the upper door and the upper door handle on the lower door.
- Attach each door handle with a cap screw [72] and screws
[41].
- Put the plastic cap into the hole that is opposite the upper
hinge of the upper door.
4. Reinstall the doors (See Art00986):
- Make sure each hinge bushing [74] is in the correct position.
- Put each hinge bushing into the bottom side of each
door hinge.
- Put each door in the position on the refrigerator.
NOTE: To prevent damage to the threads of the hinge pins,
turn the hinge pins by hand until tight and then tighten
with a screwdriver.
CAUTION: Apply Loctite removable thread locker (blue)
to the threads of the hinge screws before assembly to pre-
vent loosening during use. Do not allow Loctite to contact
any of the plastic surfaces of the refrigerator because it
can damage those surfaces.
- Align the hinges and put the hinge pins into each door.
- Tighten the hinge pins.
- Put the storage bins in the doors.
The ice maker is assembled to the refrigerators at the factory as
optional equipment. If the refrigerator does not have a factory
installed ice maker, one can not be added to the refrigerator at a
later time.
The refrigerator installer must connect a cold water supply line
to the solenoid valve at the rear of the refrigerator. The following
are necessary to connect the icemaker:
- 1/4 in. OD copper tubing for the water supply line.
OR
- 1/4 in. OD plastic tubing for the water supply line.
Connect the Ice Maker
(N64XIM, N64XIMXX, N84XIM, and
N84XIMXX models)
- 1/4 in. shut off valve in the water supply line. This should be
easily accessible through the lower intake vent.
Connect the water supply line:
Install a 1/4 in. OD water supply line [43] from the water shut off
valve of the vehicle to the solenoid water valve [44] at the rear of
the refrigerator (See Art01014):
NOTE: A brass compression nut [45], a brass sleeve, a plastic
sleeve [46] , and a brass insert [47] are supplied and
attached to the rear of the refrigerator (See Art01755).
- Put the compression nut and then the sleeve onto the water
supply line [43].
- For copper tubing, use the brass sleeve.
- For plastic tubing, use the plastic sleeve [46].
- For plastic tubing with .040 in. wall thickness, also use
the brass insert [47].
- Flush the water supply line until the water is clear.
- Put the tubing into the water valve until it is against the stop.
- Tighten the compression nut by hand (hard nger tight).
- Using two wrenches, tighten the compression nut 1 ½ to 2
turns.
- Open the water shut off valve of the vehicle.
- Examine the connections for leaks.
Connect the Electrical Components
AC Operation 120 volts AC voltage
(132 volts max. - 108 volts min.)
12 volts DC control voltage
(15.4 volts max. - 10.5 volts min.)
DC Operation 12 volts DC control voltage
(15.4 volts max. - 10.5 volts min.)
This refrigerator operates on these electrical sources. Operation
out of these limits may damage the refrigerator’s electrical circuit
parts and will void the warranty.
