6 Operating status messages
BU 0200 en-3118 233
Pos: 67 3 /Anlei tung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /War n meldu nge n (T abel le nüb ersc hri ft) @ 3 \mod_1361803463080_388.docx @ 59898 @ 5 @ 1
Warning messages
Display in the
SimpleBox / ControlBox
Warning
Text in the ParameterBox
Cause
• Remedy
Group Details in P700
[-02]
Pos: 674 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ W arnung C 001 [SK 180 E ... SK 5xxE] @ 2\ mod_1347456220101_388.docx @ 46975 @ @ 1
C001
1.0 Overtemp. Inverter
"Inverter overtemperature"
(inverter heat sink)
Inverter temperature monitoring
Warning: permissible temperature limit reached.
•
Reduce ambient temperature
• Check the FI fan / control cabinet ventilation
• Check the FI for dirt
Pos: 675 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ W arnung C 002 [SK 180 E/SK 2x xE/SK 5xx E/S K2xxE- FDS] @ 2\mod_1347456223954_388.docx @ 47000 @ @ 1
C002
2.0 Overtemp. Motor PTC
"Overtemperature motor
thermistor "
Warning from motor temperature sensor (triggering
threshold reached)
• Reduce motor load
• Increase motor speed
• Use external motor fan
2.1 Overtemp. Motor I²t
"Motor overtemperature I²t"
Only if I
2
t motor (P535) is
programmed.
Warning: I2t- motor monitoring (1.3 times the rated current
reached for the time period specified in (P535))
• Reduce motor load
• Increase motor speed
2.2 Overtemp. Brake r.ext
"Overtemperature of external
brake resistor "
Overtemperature via digital
input (P420 […])={13}
Warning: Temperature monitor (e.g. brake resistor) has
activated
• Digital input is Low
Pos: 676 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ W arnung C 003 [SK 180E ... SK 5xxE] @ 2\mod_1347457006237_388.docx @ 47199 @ @ 1
C003
3.0 Overcurrent, I
2
t limit
Warning: Inverter: I
2
t limit has triggered, e.g. > 1.3 x I
n
for
60s (please also note P504)
• Continuous overload at FI output
3.1 Overcurrent, chopper I
2
t
Warning: I
2
t limit for the brake chopper has triggered, 1.3x
value attained for 60s (also note P554, if present, as well as
P555, P556, P557)
• Avoid overload of brake resistance
3.5 Torque current limit
Warning: Torque current limit reached
•
Check (P112)
3.6 Current limit
Warning: Current limit reached
• Check (P536)
