6 Operating status messages
BU 0200 en-3118 237
Pos: 69 9 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ungen zum Betr iebsz usta nd/Betr iebss tör ungen (Auflis tung) /FAQ Betrie bsstör ungen _07 [S K 2xxE] @ 9\ mod_1448963477551_388.docx @ 268671 @ @ 1
Motor speed does not
correspond to setpoint
•
Analogue input function set to
"Frequency additions" and another
setpoint is present
• Check P400
• Check setting of integrated
potentiometer (P1) (SK 2x5E
only)
• P420, check active fixed
frequencies
• Check bus setpoints
• Check P104 / P105 "min. /
max. frequency"
• Check P113 "jog frequency"
Pos: 70 0 /Anlei tung en/El ektr onik/FU und St art er/6 . M eld ung en z um B etr iebs zus ta nd/B etri ebss tör ung en (A uflis tung )/F AQ Betr ie bsst örung en _08 [S K 2 xxE, SK 2 xxE- FDS] @ 9\mod_1448963473878_388.docx @ 268638 @ @ 1
Motor generating a
considerable amount of
noise (at the current limit)
and "OFF" signal is
implemented at slow speed
with little or no control,
possibly with error message
3.0
• Tracks A and B swapped round by
encoder (for speed feedback)
• Incorrect encoder resolution setting
• Encoder power supply missing
• Encoder faulty
• Check encoder connections
• Check P300, P301
• Monitor via P735
• Check encoder
Pos: 701 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Betr ie bss tör ung en (A ufli st ung) /FA Q B etri ebss tör ungen _09 [S K 1x0E, SK 2xxE, S K 2xxE-FD S] @ 9\mod_1448963460429_388.docx @ 268605 @ @ 1
Intermittent communication
error between FI and option
modules
• System bus terminating resistor not set
• Poor connection contacting
• Interference on system bus line
• Maximum system bus length exceeded
• First and last subscriber only:
Set DIP switches for
terminating resistance
• Check connections
• Connect GND of all FI
connected to system bus
• Pay attention to routing
regulations (separate routing
of signal and control cables
and mains and motor cables)
• Check cable lengths (system
bus)
Pos: 702 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Betr ie bss tör ung en (A ufli st ung) /FA Q B etri ebss tör ungen _10_T abel lenunt ersc hrift [S K 1xxE , SK 2xxE, SK xxxE-F DS] @ 9\mod_1448963453684_388.docx @ 268572 @ @ 1
Table 13: FAQ operational problems
