1.6.2 Variable Frequency Drive model code - basic device
SK 205E-370-323-A (-C) (-xxx)
Special version
IP rating: Standard = IP55, C = "coated" (IP66)
Radio interference filter: O = without, A = Class A1(C2)
Line voltage: x12 = 115 V, x23 = 230 V, x40 = 400 V
Number of power supply phases: 1xx = single phase, 3xx = 3-phase
Digits before decimal for power: 0 = 0.xx, 1 = 0x.x0, 2 = 0xx.0
Device rated power: 250 = 0.25 kW, 370 = 0.37 kW, ... 222 = 22.0 kW
Device
series:
SK 200E, SK 205E, SK 210E, SK 215E
SK 220E, SK 225E, SK 230E, SK 235E
(...) Options, only implemented if required.
Pos: 57 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 1. Allg emei n es/Ty pens chl üss el/ Ty pensc hlü ssel Fr equ enz umri cht er - Ansc hl uss einhei t [ SK 2xx E] @ 58\m od_1605693191109_14638.docx @ 2692571 @ 3 @ 1
1.6.3 Variable Frequency Drive model code – Connection unit
Sizes 1 to 3
SK TI4-1-205-1 (-C-EX)
ATEX
IP rating: Standard = IP55, C = “coated” = IP66
Power connection:
1 = 1~ 115/230 V
*, 3 = 3~ 230/400 V*
Suitable device models:
200 = SK 200E, 205 = SK 205E,
210 = SK 210E, 215 = SK 215E,
220 = SK 220E, 225 = SK 225E,
230 = SK 230E, 235 = SK 235E
Size: 1 = size 1, 2 = size 2, 3 = size 3
Device series: SK TI4 = connection unit SK TI4
*) The voltage depends on the variable frequency drive used. Please
refer to the technical data as well.
(...) Options, only implemented if required.
