Nord Drivesystems SK 515E Series User Manual

5 Parameters
BU 0540 EN-1516 39
Parameter overview, User settings
(P)
⇒
Parameter set dependent, these parameters can be set in various ways in the four
parameter sets.
[- xx]
⇒
Array parameter, a parameter can be set in different subgroups.
S
⇒
Supervisor parameter, visibility depends on P003.
Pos: 44 1 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter übers icht, Benutz ereins tell ungen SK 500E … SK 535E @ 0\mod_1328179925208_388.docx @ 13799 @ 5 @ 1
Parameter overview, user-defined settings SK 500E … SK 535E
Parameter
No. [Array]
Designation
Factory
setting
Supervisor
Setting after commissioning
P 1
P 2
P 3
P 4
OPERATING DISPLAYS
P000
Operating display
P001
Display selection
0
P002
Display factor
01:00
S
P003 Supervisor code 1
0= S parameters are hidden
1= All parameters are visible
Basic parameters
P100
Parameter set
0
S
P101
Copy parameter set
0
S
P102 (P)
Start-up time [s]
2.0/5.0
P103 (P)
Deceleration time [s]
2.0/5.0
P104 (P)
Minimum frequency [Hz]
0.0
P105 (P)
Maximum frequency [Hz]
50.0
P106 (P)
Ramp smoothing [%]
0
S
P107 (P)
Brake reaction time [s]
0.00
P108 (P)
Disconnection mode
1
S
P109 (P)
DC brake current [%]
100
S
P110 (P)
DC braking time on [s]
2.0
S
P111 (P)
P factor torque limit [%]
100
S
P112 (P)
Torque current limit [%]
401 (Off)
S
P113 (P)
Jog frequency [Hz]
0.0
S
P114 (P)
Brake ventilation time [s]
0.00
S
MOTOR DATA / CHARACTERISTIC CURVE PARAMETERS
P200 (P)
Motor list
0
P201 (P)
Nominal motor frequency [Hz]
50.0*
S
P202 (P)
Nominal speed [rpm]
1385*
S
P203 (P)
Nominal motor current [A]
4.8*
S
P204 (P)
Nominal motor voltage [V]
230*
S
P205 (P)
Nominal power [kW]
1.10 *
P206 (P)
Cos phi
0.78*
S
P207 (P)
Motor circuit0
[star=0/delta=1]
1*
S
P208 (P)
Stator resistance [W]
6.28*
S
P209 (P)
No load current [A]
3.0*
S
P210 (P)
Static boost [%]
100
S
P211 (P)
Dynamic boost [%]
100
S
P212 (P)
Slip compensation [%]
100
S
P213 (P)
Amplification ISD control [%]
100
S
P214 (P)
Torque precontrol [%]
0
S
P215 (P)
Boost precontrol [%]
0
S
P216 (P)
Time boost precontrol [s]
0.0
S
P217 (P)
Oscillation damping [%]
10
S
P218 (P)
Modulation depth [%]
100
S
P219
Auto. Flux optimisation [%]
100
S
P220 (P)
Parameter identification
0
P240 (P)
EMF voltage PMSM [V]
0
S
P241 [-01] (P)
Inductivity PMSM (d axis) [mH]
20
S
P241 [-01] (P)
Inductivity PMSM (q axis) [mH]
20
S
P243 (P)
Reluctance angle IPMSM [°]
0
S
