ORDERING REPLACEMENT PARTS
To order replacement parts, call our Customer Service Department toll-free at 1-888-825-2588, Monday through
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). When ordering parts, please be prepared to give
the following information:
• The MODEL NUMBER OF THE PRODUCT (NTL15941)
• The NAME OF THE PRODUCT (NordicTrack
®
4300 R treadmill)
• The SERIAL NUMBER OF THE PRODUCT (see the front cover of this manual)
• The KEY NUMBER AND DESCRIPTION OF THE PART(S) (see the PART LIST on page 30 and the
EXPLODED DRAWING attached in the center of this manual)
PART IDENTIFICATION CHART
For help identifying the assembly hardware, see the PART IDENTIFICATION CHART below.
31
Star Washer (29)–2
Upright Bolt (65)–4
1/4” Washer
(38)–4
3/8” Washer
(66)–8
Washer (38)–4
Star Washer (9)–6
(May be an internal Star Washer)
Extension Leg Screw (9)–2
Wheel Nut (64)–2
1” Latch Screw (123)–2
U-Nut (45)–4
1/2” Silver Screw
(97)–2
3/4” Screw (2)–8
1” Bolt (43)–4
Silver Ground
Screw (66)–1
5/16” Washer (125)–2
3/4”
Tek Screw (58)–4
3 1/2” Bolt (54)–2
3/4” Screw (38)–10
Crossbar Screw
(37)–2
Spacer Screw (60)–2
1/4” Washer (44)–4
1/4” Star W
asher
(1
11)–8
3/8” Star Washer
(55)–2
1/2” Silver Screw
(48)–1
1” Tek Screw (17)–4
2 1/2” Bolt (61)–2
3” Bolt (58)–4
4” Bolt (117)–2
1/2” Screw (5)–1
Star Washer
(106)–4
1 1/4” Tek Screw (60)–4
Crossbar Screw
(37)–2
5/16” Star Washer (63)–4
5/16” Star
Washer (77)–4
1/4” Star
Washer (76)–4
2” Bolt (36)–4
3/4” Screw (13)–10
Crossbar Screw
(53)–2
1” Bolt (8)–6
Wheel Nut (38)–2
Silver Ground
Screw (104)–1
Silver Ground
Screw (102)–1
1/4” x 3” Bolt (102)–4
3/4” Tek Screw (25)–4
4 1/2” Bolt (78)–4
2” Bolt (92)–3
Handrail Washer
(120)–2
3” Bolt (119)–2
