NordicTrack A.C.T. NTCW90907.1 User Manual

10
10. Slide the Lower Handlebar Cover (94) into the
slots in the underside of the Console (3). Attach
the Lower Handlebar Cover to the Handlebar
(
90) with two M4 x 16mm Screws (67).
10
3
94
67
90
Slots
11. Attach the Upper Handlebar Cover (93) to the
Handlebar (90) with an M4 x 16mm Screw (67).
11
93
67
90

NordicTrack A.C.T. NTCW90907.1 Specifications

General

Brand	NordicTrack
Model	A.C.T. NTCW90907.1
Category	Elliptical Trainer
Language	English
