2. WhileanotherpersonliftstherearoftheFrame(1),
attachtheRearStabilizer(6)totheFramewithfour
M8x44mmButtonScrews(84)anda SupportPlate
(104)asshown.
3. Slidea RampCover(48)ontoanM6x 16mmPatch
Screw(76)asshown.TightenthePatchScrewinto
oneendofthePivotAxle(14),whichisthelongerof
thetwoaxles.Applya smallamountoftheincluded
greasetothePivotAxle.
HaveasecondpersonholdthetwoRampSpacers
(99)againstthesidesoftheFrame(1)sothatthey
covertheindicatedtubesontheFrame.Alignthe
roundtubesontheRamp(3)withtheRampSpacers.
Make sure that the Ramp is turned as shown in
drawing 4 below. Insert the PivotAxle (14) into the
Ramp, the Ramp Spacers, and the Frame. tf neces-
sary, tap the Pivot Axle with a rubber mallet to insert it.
Slide a Ramp Cover (48) onto an M6 x 16mm Patch
Screw (76) as shown. Tighten the Patch Screw into the
open end of the Pivot Axle (14).
4. Slide an M6 Washer (64) onto an M6 x 16mm Patch
Screw (76). Tighten the Patch Screw into one end of
the Incline Axle (13). Apply a small amount of grease
to the Incline Axle.
Raise the Ramp (3). Insert the Incline Axle (13) into
the welded tube under one side of the Ramp, through
the motor screw, and then into the welded tube under
the other side of the Ramp. As you insert the Incline
Axle through the motor screw, make sure that the
motor screw does not turn.
Slide an M6 Washer (64) onto an M6 x 16mm Patch
Screw (76). Tighten the Patch Screw into the open
end of the Incline Axle (13).
1O4
3 \
48
Grease
48
76
14
99 Tubes
1
Motor
Screw
Grease
\
13
64
6
To Next Page
