13
9.15
9.04
17.50
14" diameter
(12" for 024k)
Return Duct
Opening
12" diameter
Supply Duct
Opening
3.0
5.5
1"
3.15
A
B
Back (Duct) View
L
W
18.01
Electric Heater Power Supply
Power Supply
Low Voltage Supply
Control
Access
Panel
Blower Access Panel
H
17.86
15.36
10.10
3/4" NPT
Drain Connection
1"
12.13
1.38
3.2
3.2 5.29
FIGURES & TABLES
Q5RD- Length (L) Width (W) Height (H) A B
024K 49 35 22.2 40.15 7.61
030K 49 35 30.2 40.15 7.61
036K 49 35 30.2 35.02 2.48
042K 49 35 30.2 35.02 2.48
048K 49 35 34.2 35.02 2.48
060K 49 35 38.2 35.02 2.48
Table 4. Q5RD Physical Data
Figure 9. Q5RD Unit Dimensions
Top View
Side View
