Nordyne SC038D-23A User Manual

39
1 Pipe Upflow
2 Pipe Upflow
PVC
Cap
Inlet Air
Inlet Air
Exhaust Vent
Inlet Air
Inline Drain
Plug
Option
1
Option
3
Option
4
Option
5
VIEW -A-
VIEW -B-
VIEW -C-
Inlet Air
Inline
Drain
Inlet Air
Inlet Air
Plug
Plug
Header Box Drain
Plug
Exhaust Vent
Exhaust Vent
See View
-A-
See View -A-
See View -B-
Drain Line
Attached to
3/4 x 1/2
Hose Barb
PVC TEE
and Reducer
See
View -C-
PVC
Cap
Exhaust Vent
Plug
Plug
See View
-A-
See View -A-
PVC
Cap
Plug
Exhaust Vent
See View -B-
Drain Line
Attached to
3/4 x 1/2
Hose Barb
PVC TEE
and Reducer
Option
2
X
See View -C-
(This drain not needed
if “X” is less than 6”.)
Option
6
Plug
Exhaust Vent
See
View -C-
PVC
Cap
X
See View -C-
This drain not needed
if “X” is less than 6”.
Header
Box Drain
Inline Drain
(Tubing is routed thru
the blower deck and
side of cabinet.)
Header Box Drain
1.) All drain lines must be trapped with J-Trap or field supplied loop.
2.) Drain line traps may be positioned inside or outside the cabinet.
3.) PVC Cap is optional for options 1,2 and 3 only.
NOTES:
Figure 25. Upfl ow Options
