Noritz NRC1111-DV - General Parts -1; Main Unit Components (NRC1111-DV); Main Unit Components (NRC1111-OD)

9
[NRC1111-DV]
IndoorWallMounted,PowerVent/SealedModel
* Theaboveillustrationshowsanexampleofinstallation.
The exact installation conguration may be slightly different.
Main Unit
FrontCover
WaterSupplyValve
WaterDrainValve
(withWaterFilter)
(Inside Water Inlet)
(
p.22)
PressureReliefValve
General Parts -1
IntakePipe
Flue Collar
GasSupplyValve
Drain Pipe
Discharges the
condensate.
[NRC1111-OD]
OutdoorWallMounted,PowerVentedModel
ExhaustVent
