NORPOLE NPCIM90B - Specifications; Model Specifications and Capacities

SPECIFICATIONS
Model
Dimensions (LxWxH)
Inches (mm)
Ice Making
Capacity
Bin Capacity Weight
NPCIM90B
NPCIM210
14.8” x 22.6” x 30.0”
(375 × 575 × 762 mm)
90 lbs. (41 kg)/ 24 hr 33 lbs. (15 kg)
77.2 lbs.
(35 kg)
NPCIM120H
NPCIM280
19.7” x 23.2” x 33.5”
(500 x 590 x 850 mm)
99.2 lbs.
(45 kg)
NPCIM160H
26.0” x 27.0” x 38.2”
(660 x 685 x 970 mm)
121.3 lbs.
(55 kg)
Figure 1
▲ Model NPCIM90B
a
c
b
▲ Model NPCIM120H
d
f
e
▲
Model NPCIM160H,
NPCIM210, NPCIM280
g
i
h
26.0” x 27.0” x 38.2”
(660 x 685 x 970 mm)
26.0” x 27.0” x 38.2”
(660 x 685 x 970 mm)
120 lbs. (54 kg)/ 24 hr
160 lbs. (73 kg)/ 24 hr
210 lbs. (95 kg)/ 24 hr
280 lbs. (127 kg)/ 24 hr
40 lbs. (18 kg)
80 lbs. (36 kg)
80 lbs. (36 kg)
80 lbs. (36 kg)
127.9 lbs.
(58 kg)
132.3 lbs.
(60 kg)
a. 30.0" (762mm)
b. 14.8" (375mm)
c. 22.6" (575mm)
d. 33.5" (850mm)
e. 19.7" (500mm)
f. 23.2" (590mm)
g. 38.2" (970mm)
h. 26.0" (660mm)
i. 27.0" (685mm)
7
