B64EM
A-CABINET
SWITCH SETTINGS
0 = OFF, 1 = ON
COOLING OR HEATING AIRFLOW (CFM)
DRY COIL ESP
1/5 2/6 3/7 4/8 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
0 0 0 0 585 550 520 460 420 405 — —
1 0 0 0 710 670 650 610 560 530 475 440
0 1 0 0 845 790 765 715 680 655 625 580
1 1 0 0 890 865 840 785 760 710 680 655
0 0 1 0 955 925 900 850 825 790 770 720
1 0 1 0 1030 995 975 940 910 870 840 815
0 1 1 0 1115 1085 1060 1020 995 965 925 905
1 1 1 0 1155 1130 1095 1070 1040 1010 985 950
0 0 0 1 1200 1175 1145 1110 1085 1060 1025 1000
1 0 0 1 1240 1215 1195 1170 1140 1110 1080 1060
0 1 0 1 1320 1290 1265 1240 1215 1185 1160 1130
1 1 0 1 1355 1330 1305 1280 1255 1220 1200 1175
0 0 1 1 1405 1375 1345 1325 1295 1275 1250 1210
1 0 1 1 1440 1415 1385 1355 1325 1290 1255 1215
0 1 1 1 1465 1425 1390 1355 1320 1290 1260 1215
1 1 1 1 1465 1425 1390 1355 1320 1290 1260 1215
B64EM
B-CABINET
SWITCH SETTINGS
0 = OFF, 1 = ON
COOLING OR HEATING AIRFLOW (CFM)
DRY COIL ESP
1/5 2/6 3/7 4/8 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
0 0 0 0 600 550 430 390 — — — —
1 0 0 0 660 610 540 460 425 — — —
0 1 0 0 830 750 695 640 580 520 — —
1 1 0 0 860 825 765 690 630 600 525 485
0 0 1 0 935 895 835 790 710 655 620 585
1 0 1 0 1045 975 920 875 830 795 720 685
0 1 1 0 1095 1040 995 950 900 850 805 750
1 1 1 0 1155 1105 1060 1010 965 920 870 825
0 0 0 1 1230 1185 1140 1090 1045 1010 965 920
1 0 0 1 1285 1260 1210 1165 1125 1080 1040 1010
0 1 0 1 1330 1290 1245 1205 1170 1125 1085 1045
1 1 0 1 1395 1365 1315 1275 1235 1205 1160 1130
0 0 1 1 1450 1405 1375 1335 1295 1260 1220 1180
1 0 1 1 1490 1450 1410 1385 1340 1300 1270 1230
0 1 1 1 1530 1485 1460 1425 1380 1350 1310 1280
1 1 1 1 1530 1490 1465 1425 1390 1350 1310 1285
B64EM
C-CABINET
SWITCH SETTINGS
0 = OFF, 1 = ON
COOLING OR HEATING AIRFLOW (CFM)
DRY COIL ESP
1/5 2/6 3/7 4/8 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
0 0 0 0 720 610 510 420 335 -- -- --
1 0 0 0 880 780 685 595 505 425 -- --
0 1 0 0 1035 940 850 765 690 620 560 --
1 1 0 0 1130 1050 975 900 830 760 695 630
0 0 1 0 1275 1195 1120 1050 985 920 865 815
1 0 1 0 1365 1295 1230 1165 1100 1035 975 915
0 1 1 0 1490 1425 1360 1300 1240 1185 1130 1075
1 1 1 0 1580 1525 1465 1410 1355 1300 1245 1190
0 0 0 1 1685 1630 1575 1520 1465 1410 1355 1300
1 0 0 1 1750 1695 1640 1585 1535 1480 1430 1375
0 1 0 1 1840 1785 1730 1680 1625 1575 1530 1480
1 1 0 1 1895 1850 1800 1750 1700 1650 1595 1540
0 0 1 1 1980 1930 1880 1830 1780 1735 1685 1640
1 0 1 1 2045 1995 1945 1895 1845 1795 1750 1700
0 1 1 1 2095 2045 1995 1945 1895 1845 1800 1755
1 1 1 1 2170 2120 2070 2020 1970 1925 1875 1830
Table 6. B64EM (FSHE) Airflow Data
