Table 2. Blower Data
HEAT RISE DATA (BASED ON NOMINAL 10KW ELECTRIC HEAT KIT)
UNIT
BLOWER
SETTING
EXTERNAL STATIC PRESSURE DROP - INCHES WATER COLUMN
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
018K
Tap T1 609 52 541 58 522 61 450 70 390 81 333 95 - - - -
Tap T2* 729 43 690 46 651 49 599 53 542 58 475 67 421 75 357 88
Tap T3 859 37 813 39 768 41 724 44 673 47 609 52 555 57 497 64
Tap T4** 1123 28 1100 29 1065 30 1023 31 978 32 929 34 877 36 820 39
Tap T5 1359 23 1320 24 1302 24 1280 25 1243 25 1205 26 1162 27 1112 28
024K
Tap T1* 950 33 823 38 881 36 832 38 788 40 722 44 655 48 593 53
Tap T2** 1123 28 1100 29 1065 30 1023 31 978 32 929 34 877 36 820 39
Tap T3 1189 27 1158 27 1141 28 1084 29 1047 30 1009 31 959 33 906 35
Tap T4 1291 24 1246 25 1236 26 1195 26 1161 27 1120 28 1075 29 1031 31
Tap T5 1359 23 1320 24 1302 24 1280 25 1243 25 1205 26 1162 27 1112 28
030K
Tap T1 965 33 910 35 870 36 800 39 720 44 665 48 615 51 560 56
Tap T2** 1100 29 1050 30 1010 31 955 33 890 35 830 38 750 42 700 45
Tap T3* 1160 27 1120 28 1080 29 1030 31 980 32 930 34 880 36 800 39
Tap T4 1440 22 1400 23 1360 23 1320 24 1280 25 1220 26 1180 27 1120 28
Tap T5 1560 20 1530 21 1490 21 1440 22 1400 23 1360 23 1310 24 1270 25
036K
Tap T1** 1215 26 1175 27 1130 28 1075 29 1020 31 970 33 900 35 840 38
Tap T2 1313 24 1277 25 1236 26 1190 27 1153 27 1104 29 1051 30 992 32
Tap T3 1460 22 1415 22 1385 23 1335 24 1275 25 1225 26 1170 27 1120 28
Tap T4* 1502 21 1466 22 1437 22 1388 23 1345 23 1305 24 1251 25 1204 26
Tap T5 1565 20 1525 21 1490 21 1450 22 1410 22 1370 23 1315 24 1270 25
042K
Tap T1 1375 23 1345 23 1310 24 1275 25 1240 25 1205 26 1160 27 1120 28
Tap T2**
1470 21 1435 22 1400 23 1370 23 1335 24 1300 24 1260 25 1215 26
Tap T3* 1600 20 1570 20 1535 21 1505 21 1470 21 1440 22 1400 23 1355 23
Tap T4 1715 18 1680 19 1650 19 1620 20 1585 20 1545 20 1505 21 1470 21
Tap T5 1895 17 1865 17 1830 17 1795 18 1760 18 1730 18 1695 19 1655 19
048KA
Tap T1 1375 23 1345 23 1310 24 1275 25 1240 25 1205 26 1160 27 1120 28
Tap T2** 1470 21 1435 22 1400 23 1370 23 1335 24 1300 24 1260 25 1215 26
Tap T3 1600 20 1570 20 1535 21 1505 21 1470 21 1440 22 1400 23 1355 23
Tap T4* 1642 19 1620 20 1580 20 1545 20 1511 21 1472 21 1433 22 1390 23
Tap T5 1895 17 1865 17 1830 17 1795 18 1760 18 1730 18 1695 19 1655 19
X60KA
Tap T1** 1390 23 1350 23 1310 24 1270 25 1240 25 1205 26 1160 27 1120 28
Tap T2 1540 21 1510 21 1480 21 1440 22 1410 22 1380 23 1340 24 1310 24
Tap T3 1700 19 1670 19 1630 19 1600 20 1580 20 1540 21 1510 21 1480 21
Tap T4* 1800 18 1762 18 1737 18 1705 19 1661 19 1630 19 1600 20 1565 20
Tap T5 2080 15 2030 16 2020 16 1970 16 1940 16 1910 17 1870 17 1840 17
NOTES
Temperature rises shaded gray are for reference only. These conditions are not recommended.
* Denotes factory set cooling speed
** Denotes factory set electric heating speed
Start-Up Procedure
CAUTION:
If the unit is equipped with a crankcase heater,
allow 24 hours prior to continuing the start up
procedures to allow for heating of the refrigerant
compressor crankcase. Failure to comply may
result in damage and could cause premature
failure of the system. This warning should be
followed at initial start up and any time the power
has been removed for 12 hours or longer.
The control circuit thermostat may consist of an anti-short cycle
timer that will not let the compressor re-start before 5 minutes
have elapsed.
1. Set the system mode to OFF and the temperature mode to
its highest setting.
2. Turn power on at the disconnect switch.
3. Set the system mode to ON or COOL.
4. Set the temperature mode below room temperature. Verify
that the indoor blower, outdoor fan, and compressor energize
and the cooling function starts.
5. Verify the discharge air grilles are adjusted and the system
air is balanced.
6. Verify the duct work has no air leaks.
7. Verify the condensate drain is installed correctly and functions
properly.
