WLAN 2300 Series Outdoor Solution with Indoor Mounted AP 41
Nortel WLAN 2300 Series Outdoor Solution Guide
WLAN 2300 Series Outdoor Solution
with Indoor Mounted AP
Introduction
This chapter provides the basic outdoor installation instructions for WLAN 2300 Series Outdoor Solution,
where the access point is mounted indoors.
Kit Contents
The Nortel WLAN 2300 Series Outdoor Solution with Indoor Mounted AP consists of the following
components:
An access point, a surge protector and grounding block, and an external antenna. Figure 1 shows a typical
installation.
The access point is mounted indoors and external antennas are typically mounted outdoors, the surge protector
and grounding block is installed outdoors at the building entrance. This document describes the solution
mounting procedures only.
Figure 1. Nortel WLAN 2300 Series Outdoor Solution with Indoor Mounted AP
